Dot Violet Laser Module 405nm 2.5mW Laser Module 12x40mm

Product Details:

Place of Origin:	CHINA
Brand Name:	AIMLASER, ELITELASER
Certification:	FDA
Model Number:	VB405D05VG1

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	USD
Packaging Details:	Anti-Static Bag or PE Bag
Delivery Time:	2-4 Weeks
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	20,000pcs/Month

Contact Now

Detailed Product Description

Wavelength:	405nm	Output Power:	2.5mW
Laser Type:	Dot Laser	CDRH Class:	Class IIIa Laser, CDRH/ROHS Compatible
Dimensions:	12 X 40mm (APC Inside)	Case Material:	Brass

EL405D05VG1 Violet Laser Module 405nm 2.5mW Laser Module , Dot Violet Laser Diode Module 3V 12x40mm

1. Descriptions:

The VB405D05VG1 is a violet dot laser subassembly with collimated beam. The maximum laser output
power is 2.5mW at 405nm.

2. Features:

Wavelength: 405nm
Optical output power: ≤2.5mW
Low operating current: <60mA
Low operating voltage: 6VDC
Class IIIa laser, CDRH/ROHS compatible
Static, Surge, and Reverse Polarity Protected
Circuit control: Auto power control (APC)
Operating Temperature: -10 to 50°C

3. Optical and Electrical Characteristics:

Wavelength: 405nm
Output Power: ≤2.5mw
Laser Modes: CW
Output Aperture: Dia 4.5mm
Beam Size: <￠5mm (@10m) and <￠10mm (@20m)
Divergence: <0.2mrad
Optics: Glass lens
Operating Current: <60mA
Operating Voltage: 6VDC
CDRH Class: Class IIIa
MTTF: 10000 Hrs.

4. Mechanical Characteristics:

Dimensions: 12x40mm (APC inside)
Cable Length: 100mm
Case Materia: Brass

5. Why Choose us?

13 years rich industry experience since 2003
SGS TUV assessed supplier
Have FDA, ISO9001:2008, IEC certificates
Cooperation with Top 500 Global Companies like GE, Corning etc.

6. Delivery & Payment Information:

Shipment Term: FOB Xi’an, China.
Payment Terms: T/T, Western Union, Paypal
Shipping Method: DHL/UPS/TNT/FedEx Air-Express

7. Elite Factory Over view:

Established in 2003, Elite Optoelectronics Co., LTD. covering an area of 2,200 sq.m with 120 staffs, is a professional designer and manufacturer of laser diode modules, Bios lasers, fiber coupled laser modules, DPSS laser modules, laser line projector, laser bore sighters, laser sights etc.
