520nm 5mW green dot mini laser module with PD for Laser Aiming Devices FDA Certified

MN520-10FBM Mini Laser Diode Module 520nm 5mW green dot laser module with FDA Certificate

1. Description:

The MN520-10FBM is a green mini laser module subassembly with collimated beam. The maximum laser
output power is 5.0 mW at 520nm.

2. Features:

• Wavelength: 520±5 nm
• High brightness, optical output power: ≤ 5.0 mW
• Low operating current: <20 mA
• Low operating voltage: 3.0 VDC
• Class IIIa laser, CDRH/ROHS compatible
• Static, Surge, and Reverse Polarity Protected
• Circuit control: Auto power control (APC)
• Operating Temperature: -10 to 50°C

3. Optical and Electrical Characteristics:

• Wavelength: 520±10 nm
• Average Power: >1.0mw
• Peak Power: ≤ 5.0 mw
• Laser Modes: Pulse
• Output Aperture:￠2.0mm
• Beam Size:< 5x12 mm (@10m) and < 10x22mm (@20m)
• Divergence: 0.8mrad
• Optics: Glass lens
• Operating Current <20mA T c = 253°C
• Operating Voltage: 3.0 VDC
• CDRH Class: Class IIIa
• MTTF: 8000 Hrs.

4. Mechanical Characteristics:

• Dimensions:￠4.0(D) x 10.0(L1)mm (APC outside)
• Cable Length: 50mm 30AWG
• Case Material: Brass

5. Mini Laser Module Applications:

• Laser alignment, aiming, positioning and pointing
• b.Gun laser sight
• c.Military instrument and equipment
• d.Bar code scan

6. Packaging and Payment Information:

• MOQ: 10pcs.
• Packaging Details: Each packed into static free plastic bag, bulk into export cartons.
• Shipment Term: FOB Xi’an, China.
• Shipping Method: DHL/EMS/TNT Air-Express

7. ​Why Choose us?

• 13 years rich industry experience since 2003
• SGS TUV assessed supplier
• Have FDA, ISO9001:2008, IEC certificates
• Cooperation with Top 500 Global Companies like GE, Corning etc.
