MN650-05FC 650nm 3mW 3-5VDC Red Dot Mini Laser Diode Module, Beam Size 8*16mm at 20m

Product Details:

Place of Origin:	CHINA
Brand Name:	AIMLASER, ELITELASER
Certification:	FDA
Model Number:	MN650-05FC Red Mini Laser Module

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	FOB Xi'an China
Packaging Details:	Anti-Static Bag or PE Bag
Delivery Time:	2-4 Weeks
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	20,000pcs/Month

Contact Now

Detailed Product Description

**650nm 3mW Red Dot Laser, Mini Laser Module, 3-5V DC, CW Mode, Beam Size 8*16mm at 20m**

MN650-05FC Compact Laser Dot Modules

1.Descriptions

The MN650-05FC is a red dot laser subassembly with collimated beam. The maximum laser output power is 3.0 mW at 650nm.

2.Optical and Electrical Characteristics

Wavelength: 650nm
Output Power: ≤3.0mW

Laser Modes: CW
Output Aperture:Dia.3.0mm
Beam Size: 8*16mm (@20m)
Divergence:0.4mrad
Optics:Glass lens
Operating Current:<30mA
Operating Voltage:3-5VDC
MTTF:10000Hrs

Material: Brass

Module Size:6*12mm

CDRH Class: Class IIIa, CDRH/ROHS compatible

Circuit Protection:Static, Surge, and Reverse Polarity Protected

Circuit control: Auto power control (APC)
Operating Temperature: -10 to 50°C

3.Elite Laser Diode Module Applications:

a.Industrial laser alignment, positioning, pointing, surveying and detection equipment

b. Medical laser treatment instruments

c.3D measurement

d. Metrology equipment

e.Laser test equipment, fire alarm system

f.Laser analytical instrument

g.Chemical analysis, biological analysis

h.Laser diagnostics

i.Microfluidic system

g. Laser gas analysis

k.Oral dental lasers

l.Biomedical analysis

m.DNA sequencing, life science

n.Laboratory equipment, scientific research

o. laser barcode reader

p.Laser tools etc.

4. Why Choose us?

12 years rich industry experience since 2003

SGS TUV assessed supplier

Have FDA, ISO9001:2008, IEC certificates

Cooperation with Top 500 Global Companies like GE, Corning etc.

5. Packaging & Delivery & Payment Information:

MOQ: 2pcs.

Payment Terms: T/T, Western Union, Paypal

Shipping Method: DHL/EMS/TNT Air-Express or sea transportation.

6.Warranty:

We offer 12 months limited warranty for our products. Damage due to misuse, ill treatment and unauthorized modifications and repairs are not covered by our warranty.

7.CAUTION:

The laser light is harmful to human body especially to eye no matter what directly or indirectly. The laser beam shall be observed or adjusted through infrared camera or equivalent.
