Elite 450nm Blue Laser Module 1mW-60mW

Product Details:

Place of Origin:	CHINA
Brand Name:	AIMLASER, ELITELASER
Certification:	FDA
Model Number:	450nm Blue Laser Module

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	FOB Xi'an China
Packaging Details:	Anti-Static Bag or PE Bag
Delivery Time:	2-4 Weeks
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	20,000pcs/Month

Contact Now

Detailed Product Description

Laser Module, 445nm Laser Module, 5mW-200mW 445nm Laser Diode Module Dot & Line Beam with Built-in PD

1.Elite 445nm Laser Diode Module Description:

Elite could provide high quality 445nm (Blue) 5mw-200mw Dot & Line laser diode module. Except the models listed below, several more options are available.

Elite could also do customized new Blue Violet & Green Laser Diode Module.

2.Elite 445nm Laser Diode Module Features:

a. High stability and high reliability

b. Compact size

c. Low power consumption

d. Customized solutions for OEM applications

3.Elite 445nm Laser Diode Module (Dot Beam)Specifications:

Model	Wave Length	Output Power	Driver	Aperture	Divergence	Beam Size	Dimension
VB445D05VG1	445nm	<3.5mW	APC	Dia.4.5mm	0.2mrad	Dia.5mm@10m	Dia.10x35mm
VB445D05VG2	445nm	<5.0mW	APC	Dia.5.0mm	0.2mrad	4x8mm@10m	Dia.12x40mm
VB445D05VG3	445nm	<3.0mW	APC	Dia.6.0mm	0.1mrad	Dia.6mm@20m	Dia.14x50mm
VB445D10VG1	445nm	<7.0mW	APC	Dia.4.5mm	0.1mrad	Dia.5mm@10m	Dia.10x35mm
VB445D10VG2	445nm	<10.0mW	APC	Dia.5.0mm	0.2mrad	4x8mm@10m	Dia.12x40mm
VB445D10VG3	445nm	<6.0mW	APC	Dia.6.0mm	0.1mrad	Dia.6mm@20m	Dia.14x50mm
VB445D20VG1	445nm	<10.0mW	APC	Dia.4.5mm	0.1mrad	Dia.8mm@20m	Dia.12x40mm
VB445D20VG2	445nm	<14.0mW	APC	Dia.5.0mm	0.2mrad	6x12mm@20m	Dia.12x40mm
VB445D20VG3	445nm	<10.0mW	APC	Dia.6.0mm	0.1mrad	Dia.6mm@20m	Dia.14x50mm
VB445D40VG1	445nm	<20.0mW	APC	Dia.4.5mm	0.1mrad	Dia.8mm@20m	Dia.14x50mm
VB445D40VG2	445nm	<28.0mW	APC	Dia.5.0mm	0.2mrad	6x12mm@20m	Dia.14x50mm
VB445D40VG3	445nm	<20.0mW	APC	Dia.6.0mm	0.1mrad	Dia.6mm@20m	Dia.14x50mm
VB445D60VG1	445nm	<30.0mW	APC	Dia.4.5mm	0.1mrad	Dia.8mm@20m	Dia.14x50mm
VB445D60VG2	445nm	<40.0mW	APC	Dia.5.0mm	0.2mrad	6x12mm@20m	Dia.14x50mm
VB445D60VG3	445nm	<40.0mW	APC	Dia.6.0mm	0.1mrad	Dia.6mm@20m	Dia.14x50mm
VB445D100VG1	445nm	<50.0mW	APC	Dia.4.5mm	0.1mrad	Dia.8mm@20m	Dia.16x60mm
VB445D100VG2	445nm	<70.0mW	APC	Dia.5.0mm	0.2mrad	6x12mm@20m	Dia.16x60mm
VB445D100VG3	445nm	<60.0mW	APC	Dia.6.0mm	0.1mrad	Dia.6mm@20m	Dia.14x50mm

4. Elite 445nm Laser Diode Module Applications:

a. Laser alignment and positioning

b. Industrial instruments and equipments

c. Medical Treatment Instruments

d. Other OEM applications……

5. Why Choose us?

12 years rich industry experience since 2003

SGS TUV assessed supplier

Have FDA, ISO9001:2008, IEC certificates

Cooperation with Top 500 Global Companies like GE, Corning etc.

6. Packaging & Delivery & Payment Information:

MOQ: 10pcs.

Supply Ability: 100,000pcs per month.

Delivery Time: 10-20 days depending on order quantity.

Shipment Term: FOB Xi’an, China.

Payment Terms: T/T, Western Union, Paypal

Shipping Method: DHL/EMS/TNT Air-Express or sea transportation.

7.Warranty:

We offer 12 months limited warranty for our products. Damage due to misuse, ill treatment and unauthorized modifications and repairs are not covered by our warranty.

8.CAUTION:

The laser light is harmful to human body especially to eye no matter what directly or indirectly. The laser beam shall be observed or adjusted through infrared camera or equivalent.

9.Elite QC Flow:

a.Professional Power Meter for double check

b.Qualified professional staff for the beam size/line thickness testing

c.Strictly surface Inspection before load to the warehouse

10.Elite Factory:

Company Dept Photo.png
